Platinum Sponsor |
|
|
|
We, Confovis GmbH based in Jena (Germany), are a developer and manufacturer of instruments for automated optical inspection (WAFERinspect AOI) and optical 3D surface metrology (TOOLinspect) for the semiconductor industry. Our devices enable precise defect inspection, classification and dimensional measurements, for example for surface topography in statistical process control. Unlike other AOI systems, our solutions are versatile due to their unique hardware. Adjustments in defect inspection recipes, as well as classifications can be made directly via the Graphical User Interface (GUI). Hence, the defect classes are taught by short GUI-supported learning, using rule-based artificial intelligence. |
|
|
|
Silver Sponsor |
|
|
|
JX Advanced Metals provides high quality sputtering targets for semiconductor devices, flat panel displays, magnetic devices, photovoltaic cells and various other applications. Through years of research, development, and production activities, we have developed technologies in areas such as high-purity, low-inclusion casting, powder metallurgy, and structure control, that are essential for demanding thin-film metal deposition processes. In addition to our broad range of sputtering targets, we offer compound semiconductor materials for telecom and data communications, as well as high purity metals for epi-growth processes. For more information on our leading-edge electronic materials, please visit our online showroom at https://nmmjx-dc.com/en/. |
|
|
|
|
Infineon has around 57,000 employees from over 100 countries and is one of the world’s leading companies in the semiconductor industry. The Infineon Dresden manufacturing site was founded in 1994, at that time still as part of Siemens. Today, Dresden is one of the most modern and largest sites for manufacturing, technology, and product development, and now employs more than 4,000 people. This makes Infineon Dresden one of the most important industrial employers in the region.
Today, Infineon Dresden manufactures over 400 different products based on 200mm and 300mm wafers – quickly and with the highest quality. Our products meet the highest security standards – particularly important for security and chip card products as well as automotive electronics.
Infineon Dresden participates in research, development and innovation projects within future-oriented technology and product fields for topics such as future mobility, energy supply, data security and artificial intelligence. We work together with regional, national and international partners in research collaborations. |
|
|
|
|
VON ARDENNE develops and manufactures systems for the industrial vacuum coating of materials such as glass, wafers, metal strip or polymer films. Our customers use these materials to manufacture high-quality products such as solar cells, architectural glass, fuel cells , semiconductors or microelectronic components for sensors and optics. With more than 60 years of experience in electron beam technology and over 50 years of experience in magnetron sputtering, VON ARDENNE is a pioneer and world-leading supplier of equipment and technologies in PVD thin-film and vacuum process technology. |
|
|
|
|
ErzM-Technologies is a semiconductor consulting company, based in Chemnitz, Germany.
The company was founded in 2015 by Knut Gottfried, head surface processing at the Fraunhofer Institute ENAS in Chemnitz. He is also chairman of the European CMP & WET Users Group.
Due to worldwide connections to semiconductor suppliers, institutes and companies ErzM-Technologies provides a great network of solutions. ErzM-Technologies offers strategy guidance, process and technology development and foundry services along the full semiconductor chip cycle, such as CMP, Wet Processing, ECD, Plasma Processing, Lithography, Wafer Level Packaging / Bonding and a broad variety of Wafer Characterization techniques. |
|
|
|
|
|
